DMC169 - HX4 with 27 Dies and Micrometer M83507/9-01

Daniels Manufacturing CorporationSKU: EG-0020
Preço:
Request pricing

Ship Date:
Special Order

Documentation

Descrição

The DMC169 Tool Kit contains the HX4 (M22520/5-01) associated Die Sets for MIL-Spec shielding ferrules (MS21980/MS21981) and MIL-Spec coaxial contacts (MS39029/6, /13, /14, M39029/7, /8, M83733/13. /14 and 0N089558).

The kit is supplied in a metal case with foam inserts, contoured tool cavities, laminated instruction sheets permanently attached on a ring binder, and contents charts identifying the location of each tool.

Tool Kit Configuration:

Type of Case:  Portable
Number of Cases:  1
Color:  Gray
Type of Construction:  Steel/Aluminum
Application:  M22520/5-01
Type of Inserts:  Unicellular Polyethylene Foam with Die Cut Tool Cavities

Specification Value
Shipping Weight 22.0 LBS
Military Part Number M83507/9-01
National Stocking Number 5180001668336
